Guide screw: a new building material tool, which is used to transfer the overall lifting stress of the building and adjust the support, including: support rod, reinforcing rib, support surface. The support rod is fixed below the support surface, and the fixing and connection between the reinforcing rib and the support rod. It is equipped with an adjusting screw at the lower end of each support rod, and a slot shaped sliding base is set above the support surface, A sliding plate is placed in the sliding base and an adjusting lead screw is set at one side. The end of the adjusting lead screw is against the sliding plate, and the sliding plate can slide under the action of the lead screw. The sliding plate has the characteristics of stable and reliable stress transfer of the support, and convenient position offset adjustment when the building is raised.

导轨丝杠特点：

Features of guide screw:

1、按照国标GB/T17587.3-1998及应用实例，滚珠丝杠（已基本取代

1. According to the national standard GB/T17,587.3-1998 and application examples, the ball screw (basically replaced

梯形丝杆，俗称丝杆）是用来将旋转运动转化为直线运动；或将直线运动转化为旋转运动的执行元件，并具有传动效率高，定位准确等

Trapezoidal screw rod, commonly known as screw rod) is used to convert rotary motion into linear motion; Or it can convert linear motion into rotary motion, with high transmission efficiency, accurate positioning, etc

2、当滚珠丝杠作为主动体时，螺母就会随丝杆的转动角度按照对应规格的导程转化成直线运动，被动工件可以通过螺母座和螺母连接，从而实现对应的直线运动。

2. When the ball screw is used as the active body, the nut will be converted into linear motion according to the lead of the corresponding specification with the rotation angle of the screw rod, and the passive workpiece can be connected with the nut through the nut seat, thus realizing the corresponding linear motion.

应用

application

高DN值滚珠丝杠：高速工具机，高速综合加工机

High DN ball screw: high-speed tool machine, high-speed integrated machining center machine

端盖式滚珠丝杠：快速搬运系统，一般产业机械，自动化机械

End cap ball screw: quick handling system, general industrial machinery, automation machinery

高速化滚珠丝杠：CNC机械、精密工具机、产业机械、电子机械、高速化机械

High speed ball screw: CNC machinery, precision tool machine, industrial machinery, electronic machinery, high speed machinery

精密研磨级滚珠丝杠：CNC机械，精密工具机，产业机械，电子机械，输送机械，航天工业，其它天线使用的致动器、阀门开关装置等

Precision grinding ball screw: CNC machinery, precision tool machine, industrial machinery, electronic machinery, conveying machinery, aerospace industry, actuators and valve switches for other antennas

螺帽旋转式（R1）系列滚珠丝杠：半导体机械、产业用机器人、木工机、雷射加工机、搬送装置等

Screw cap rotary (R1) series ball screw: semiconductor machinery, industrial robots, woodworking machines, laser processing machines, conveying devices, etc

轧制级滚珠丝杠：低摩擦、运转顺畅的优点，同时供货迅速且价格低廉

Rolling grade ball screw: low friction, smooth operation, fast supply and low price

重负荷滚珠丝杠：全电式射出成形机、冲压机、半导体制造装置、重负荷制动器、产业机械、锻压机械

Heavy duty ball screw: full electric injection molding machine, stamping machine, semiconductor manufacturing device, heavy duty brake, industrial machinery, forging machinery
